Product Details
Place of Origin: China
Certification: Design Patent Certificate,Computer Software Copyright Registration Certificate,Utility Model Patent Certificate,Testing Report of Lightning Protection Products Testing Center of Shanghai Lightning Protection Center, etc.
Model Number: JDY-500
Payment & Shipping Terms
Minimum Order Quantity: 1
Price: ＄16750
Packaging Details: Flight Case
Delivery Time: 30 days
Payment Terms: D/A,L/C,D/P,Western Union,T/T,MoneyGram
Supply Ability: 200 per month
|
Product Name:
|
JDY-500 Fixed UAV Detection System
|
Core Tech:
|
Passive Detection, Spectrum Sensing, AI Identification
|
Detection Freq:
|
300MHz~6000MHz
|
Key Detection Bands:
|
2.4G/5.8G/800MHz/900MHz/1.1G/1.2G/1.4GHz
|
Detection Dist:
|
1~3km (depends On Electromagnetic Environment)
|
Positioning Accuracy:
|
≤10m (UAV); ≤5m (operator, Partial)
|
False Alarm Rate:
|
≤1 Time/12 Hours
|
Alarm Mode:
|
Audible/visual (adjustable/silent)
|
Power Supply:
|
AC220V→DC24V
|
Working Time:
|
7×24 Hours Continuous Operation
|
Weight:
|
≤3kg (w/o Tripod); ≤12kg (w/o Tripod & Antenna)
|
Operating Temp:
|
-35℃~50℃; -30℃~75℃ (partial)
|
Protection Level:
|
IP66
|
Networking:
|
4G/5G (optional), LAN (RJ45)
|
Control Platform:
|
Optional (B/S, GIS, Blacklist/whitelist)
|
|
Product Name:
|
JDY-500 Fixed UAV Detection System
|
|
Core Tech:
|
Passive Detection, Spectrum Sensing, AI Identification
|
|
Detection Freq:
|
300MHz~6000MHz
|
|
Key Detection Bands:
|
2.4G/5.8G/800MHz/900MHz/1.1G/1.2G/1.4GHz
|
|
Detection Dist:
|
1~3km (depends On Electromagnetic Environment)
|
|
Positioning Accuracy:
|
≤10m (UAV); ≤5m (operator, Partial)
|
|
False Alarm Rate:
|
≤1 Time/12 Hours
|
|
Alarm Mode:
|
Audible/visual (adjustable/silent)
|
|
Power Supply:
|
AC220V→DC24V
|
|
Working Time:
|
7×24 Hours Continuous Operation
|
|
Weight:
|
≤3kg (w/o Tripod); ≤12kg (w/o Tripod & Antenna)
|
|
Operating Temp:
|
-35℃~50℃; -30℃~75℃ (partial)
|
|
Protection Level:
|
IP66
|
|
Networking:
|
4G/5G (optional), LAN (RJ45)
|
|
Control Platform:
|
Optional (B/S, GIS, Blacklist/whitelist)
|
The fixed drone detection system (Drone Detector) is an advanced defense solution designed to address low-altitude drone threats. Utilizing a highly sensitive receiver module and directional antenna, the system enables real-time detection, accurate identification, and rapid early warning of illegal drones. Whether at airports, prisons, power plants, government agencies, or large-scale events, it ensures low-altitude safety and prevents potential safety hazards posed by drones.
The device offers long-term operation and supports harsh outdoor environments, featuring dustproof, waterproof, and lightning-proof design.
Multi-band coverage identifies remote control links, image transmission signals, and navigation frequencies, enabling rapid differentiation between different drone models.
Access platforms via Ethernet, 4G/5G, or fiber optic networks enable remote centralized monitoring and alert push.
A single device can provide fixed detection over a range of several kilometers, and multiple devices can form a grid-based defense system.
Can be integrated with fixed drone jammers and video surveillance platforms to create an integrated "detection + countermeasure + tracking" solution.
Prevent drones from disrupting flight operations.
Prevent drones from delivering contraband.
Protect critical infrastructure such as power facilities and petrochemical plants.
Ensure airspace security for concerts, exhibitions, and sporting events.
The Drone Detector fixed drone detection system offers high sensitivity, stability, reliability, and wide coverage, enabling customers to effectively build low-altitude defense networks and ensure regional security.
