Home > Products > Anti Drone System > Full Band Drone Jamming System Customizable Frequency IP65 Multi Functional

Full Band Drone Jamming System Customizable Frequency IP65 Multi Functional

Product Details

Place of Origin: China

Certification: Design Patent Certificate,Computer Software Copyright Registration Certificate,Utility Model Patent Certificate,Testing Report of Lightning Protection Products Testing Center of Shanghai Lightning Protection Center, etc.

Model Number: JDY-900P

Payment & Shipping Terms

Minimum Order Quantity: 1

Price: $44670

Packaging Details: Flight Case

Delivery Time: 30 days

Payment Terms: T/T,L/C,D/A,D/P,Western Union,MoneyGram

Supply Ability: 200 per month

Chat Now
Highlight:

Customizable Drone Jamming System

,

Customizable jammer for drones

,

IP65 Drone Jamming System

Product Name:
Jdy-900(P) Anti-Uav Single-Station Defense System
Core Tech:
Passive Detection, Wideband Scanning
Detection Freq:
300MHz~6000MHz; 300MHz~9000MHz (Partial)
Key Detection Bands:
2.4G/5.8g/800MHz/900MHz/1.4G/5.2GHz
Detection Dist:
Jdy-900:1~5km; Jdy-900p:1~8km
Positioning Accuracy:
≤10m (Uav); ≤5m (Operator)
Jamming Bands:
2.4G/5.8g/900MHz/GPS/Bds/Glonass/Galileo
Jamming Dist:
1~3km (Depends On Electromagnetic Environment)
Jamming Method:
4-Sector Directional/Omnidirectional Strike
Transmission Power:
360W; 1500W (Partial Versions)
Power Supply:
AC220V→DC24V; DC27V (Partial)
Weight:
≤20.0kg
Operating Temp:
-35ºC~50ºC (Built-in Radiator)
Protection Level:
IP66; IP65 (Partial)
Alarm Mode:
Audible/Visual Alarm
Product Name:
Jdy-900(P) Anti-Uav Single-Station Defense System
Core Tech:
Passive Detection, Wideband Scanning
Detection Freq:
300MHz~6000MHz; 300MHz~9000MHz (Partial)
Key Detection Bands:
2.4G/5.8g/800MHz/900MHz/1.4G/5.2GHz
Detection Dist:
Jdy-900:1~5km; Jdy-900p:1~8km
Positioning Accuracy:
≤10m (Uav); ≤5m (Operator)
Jamming Bands:
2.4G/5.8g/900MHz/GPS/Bds/Glonass/Galileo
Jamming Dist:
1~3km (Depends On Electromagnetic Environment)
Jamming Method:
4-Sector Directional/Omnidirectional Strike
Transmission Power:
360W; 1500W (Partial Versions)
Power Supply:
AC220V→DC24V; DC27V (Partial)
Weight:
≤20.0kg
Operating Temp:
-35ºC~50ºC (Built-in Radiator)
Protection Level:
IP66; IP65 (Partial)
Alarm Mode:
Audible/Visual Alarm
Full Band Drone Jamming System Customizable Frequency IP65 Multi Functional
JDY-900(P) Anti-Drone Single-Station Defense System
Why Choose the JDY-900(P)?

Amidst the increasing threat of low-altitude air defense, the JDY-900(P) offers users an efficient and simple anti-Drone solution with a "one-stop defense" concept.

Five Core Selling Points
  • Multi-Functional: Detection, positioning, and jamming are integrated into a single device, eliminating the need for multiple devices.
  • Quick Deployment: Supports fixed, portable, and vehicle-mounted installation options, enabling deployment in minutes.
  • Precision Strike: Capable of identifying and jamming mainstream consumer drones, including DJI O2/O3/O4 protocol models.
  • Intelligent Operation: Unattended mode automatically determines and executes the optimal countermeasure strategy based on the intrusion level.
  • Safe and Reliable: Minimizes interference with nearby normal communications and legitimate drones, preventing accidental injuries.
Application Value
  • Government Security: Prevents drone voyeurism and nuisance in conference venues, courtrooms, and office parks.
  • Transportation hubs: Prevent unauthorized drones from disrupting operations at airports and along railway lines.
  • Enterprises and industries: Protect energy, chemical, and communications facilities from drone surveillance or sabotage.
  • Large-scale events: Temporary deployment at sporting events, concerts, and exhibitions to ensure crowd safety.

The JDY-900(P) makes low-altitude protection more efficient and intelligent, truly realizing the value of "single-station security."

Product Name Jdy-900(P) Anti-UAV Single-Station Defense System
Core Technology Passive Detection, Broadband Scanning
Detection Frequency 300MHz to 6000MHz; 300MHz to 9000MHz (select models)
Key Detection Frequency Bands 2.4GHz / 5.8GHz / 800MHz / 900MHz / 1.4GHz / 5.2GHz
Detection Range Jdy-900: 1 to 5km; Jdy-900p: 1 to 8km
Positioning Accuracy ≤10m (UAV); ≤5m (operator)
Interference Frequency Bands 2.4GHz / 5.8GHz / 900MHz / GPS / Beidou / Glonass / Galileo
Interference Range 1-3 km (depending on electromagnetic environment)
Interference Mode Four-sector directional/omnidirectional strike
Transmit Power 360W; 1500W (select models)
