5.2GHz Anti Drone System Ip66 Protection Grade Harsh Environments Resistant Fixed

Name: 5.2GHz Anti Drone System Ip66 Protection Grade Harsh Environments Resistant Fixed
Brand: AegisCloud (Shenzhen) Technology Innovation Co., Ltd.
SKU: JDY-900P
Price: 44670 USD
Availability: InStock

Product Details

Place of Origin: China

Certification: Design Patent Certificate,Computer Software Copyright Registration Certificate,Utility Model Patent Certificate,Testing Report of Lightning Protection Products Testing Center of Shanghai Lightning Protection Center, etc.

Model Number: JDY-900P

Payment & Shipping Terms

Minimum Order Quantity: 1

Price: ＄44670

Packaging Details: Flight Case

Delivery Time: 30 days

Payment Terms: T/T,L/C,D/A,D/P,Western Union,MoneyGram

Supply Ability: 200 per month

Get Best Price

Chat Now

Product Details

Product Description

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                            5.2GHz Anti Drone System, 5.2GHz military drone countermeasures, Ip66 Anti Drone System


Product Name:	Jdy-900(P) Anti-Uav Single-Station Defense System	Core Tech:	Passive Detection, Wideband Scanning
Detection Freq:	300MHz~6000MHz; 300MHz~9000MHz (Partial)	Key Detection Bands:	2.4G/5.8g/800MHz/900MHz/1.4G/5.2GHz
Detection Dist:	Jdy-900:1~5km; Jdy-900p:1~8km	Positioning Accuracy:	≤10m (Uav); ≤5m (Operator)
Jamming Bands:	2.4G/5.8g/900MHz/GPS/Bds/Glonass/Galileo	Jamming Dist:	1~3km (Depends On Electromagnetic Environment)
Jamming Method:	4-Sector Directional/Omnidirectional Strike	Transmission Power:	360W; 1500W (Partial Versions)
Power Supply:	AC220V→DC24V; DC27V (Partial)	Weight:	≤20.0kg
Operating Temp:	-35ºC~50ºC (Built-in Radiator)	Protection Level:	IP66; IP65 (Partial)
Alarm Mode:	Audible/Visual Alarm

Product Name:	Jdy-900(P) Anti-Uav Single-Station Defense System
Core Tech:	Passive Detection, Wideband Scanning
Detection Freq:	300MHz~6000MHz; 300MHz~9000MHz (Partial)
Key Detection Bands:	2.4G/5.8g/800MHz/900MHz/1.4G/5.2GHz
Detection Dist:	Jdy-900:1~5km; Jdy-900p:1~8km
Positioning Accuracy:	≤10m (Uav); ≤5m (Operator)
Jamming Bands:	2.4G/5.8g/900MHz/GPS/Bds/Glonass/Galileo
Jamming Dist:	1~3km (Depends On Electromagnetic Environment)
Jamming Method:	4-Sector Directional/Omnidirectional Strike
Transmission Power:	360W; 1500W (Partial Versions)
Power Supply:	AC220V→DC24V; DC27V (Partial)
Weight:	≤20.0kg
Operating Temp:	-35ºC~50ºC (Built-in Radiator)
Protection Level:	IP66; IP65 (Partial)
Alarm Mode:	Audible/Visual Alarm

5.2GHz Anti Drone System Ip66 Protection Grade Harsh Environments Resistant Fixed

Product Overview

JDY-900(P) is a highly integrated, single-station anti-drone defense system, designed to detect, locate, and counter unauthorized UAVs. With passive detection and active jamming capabilities, it offers all-in-one protection for airports, energy facilities, public events, and government premises.

Key Features

Wide Detection Range: Covers 300MHz–6000MHz, detection up to 8km, jamming up to 3km.
Accurate Tracking: UAV positioning accuracy ≤10m; pilot ≤5m.
Fast Response: Detection within 2.5s, jamming response ≤6.5s.
Flexible Deployment: Supports fixed, portable, and vehicle-mounted setups.
Reliable Operation: IP66 waterproof, -35℃~+50℃ working temperature.

Advantages

One-Station Defense: No need for complex networking, single device ensures full protection.
Comprehensive Countermeasures: Blocks control, video, and navigation signals.
Smart Management: Remote control via LAN/4G/5G, mobile app supported.
Cost-Effective: Lower investment compared to multi-station systems.

Applications

Airports & Railways
Stadiums, Concerts & Exhibitions
Prisons & Exam Centers
Power Plants & Oil Fields
Government & Military Zones

JDY-900(P) is the ideal export-ready solution for global security providers who need reliable, scalable, and efficient anti-drone defense.

Product Name	Jdy-900(P) Anti-UAV Single-Station Defense System
Core Technology	Passive Detection, Broadband Scanning
Detection Frequency	300MHz to 6000MHz; 300MHz to 9000MHz (select models)
Key Detection Frequency Bands	2.4GHz / 5.8GHz / 800MHz / 900MHz / 1.4GHz / 5.2GHz
Detection Range	Jdy-900: 1 to 5km; Jdy-900p: 1 to 8km
Positioning Accuracy	≤10m (UAV); ≤5m (operator)
Interference Frequency Bands	2.4GHz / 5.8GHz / 900MHz / GPS / Beidou / Glonass / Galileo
Interference Range	1-3 km (depending on electromagnetic environment)
Interference Mode	Four-sector directional/omnidirectional strike
Transmit Power	360W; 1500W (select models)
