Product Details
Place of Origin: China
Certification: Design Patent Certificate,Computer Software Copyright Registration Certificate,Utility Model Patent Certificate,Testing Report of Lightning Protection Products Testing Center of Shanghai Lightning Protection Center, etc.
Model Number: JDY-900P
Payment & Shipping Terms
Minimum Order Quantity: 1
Price: $44670
Packaging Details: Flight Case
Delivery Time: 30 days
Payment Terms: T/T,L/C,D/A,D/P,Western Union,MoneyGram
Supply Ability: 200 per month
Product Name:
|
Jdy-900(P) Anti-Uav Single-Station Defense System
|
Core Tech:
|
Passive Detection, Wideband Scanning
|
Detection Freq:
|
300MHz~6000MHz; 300MHz~9000MHz (Partial)
|
Key Detection Bands:
|
2.4G/5.8g/800MHz/900MHz/1.4G/5.2GHz
|
Detection Dist:
|
Jdy-900:1~5km; Jdy-900p:1~8km
|
Positioning Accuracy:
|
≤10m (Uav); ≤5m (Operator)
|
Jamming Bands:
|
2.4G/5.8g/900MHz/GPS/Bds/Glonass/Galileo
|
Jamming Dist:
|
1~3km (Depends On Electromagnetic Environment)
|
Jamming Method:
|
4-Sector Directional/Omnidirectional Strike
|
Transmission Power:
|
360W; 1500W (Partial Versions)
|
Power Supply:
|
AC220V→DC24V; DC27V (Partial)
|
Weight:
|
≤20.0kg
|
Operating Temp:
|
-35ºC~50ºC (Built-in Radiator)
|
Protection Level:
|
IP66; IP65 (Partial)
|
Alarm Mode:
|
Audible/Visual Alarm
|
Product Name:
|
Jdy-900(P) Anti-Uav Single-Station Defense System
|
Core Tech:
|
Passive Detection, Wideband Scanning
|
Detection Freq:
|
300MHz~6000MHz; 300MHz~9000MHz (Partial)
|
Key Detection Bands:
|
2.4G/5.8g/800MHz/900MHz/1.4G/5.2GHz
|
Detection Dist:
|
Jdy-900:1~5km; Jdy-900p:1~8km
|
Positioning Accuracy:
|
≤10m (Uav); ≤5m (Operator)
|
Jamming Bands:
|
2.4G/5.8g/900MHz/GPS/Bds/Glonass/Galileo
|
Jamming Dist:
|
1~3km (Depends On Electromagnetic Environment)
|
Jamming Method:
|
4-Sector Directional/Omnidirectional Strike
|
Transmission Power:
|
360W; 1500W (Partial Versions)
|
Power Supply:
|
AC220V→DC24V; DC27V (Partial)
|
Weight:
|
≤20.0kg
|
Operating Temp:
|
-35ºC~50ºC (Built-in Radiator)
|
Protection Level:
|
IP66; IP65 (Partial)
|
Alarm Mode:
|
Audible/Visual Alarm
|
Easy to use, one-stop low-altitude security.
The JDY-900(P) provides users with a plug-and-play experience. Whether for temporary or long-term deployment, a single device provides comprehensive capabilities from detection to disposal.
The JDY-900(P) eliminates the complexity of low-altitude safety, creating greater value for users with its easy deployment and high performance.
Product Name | Jdy-900(P) Anti-UAV Single-Station Defense System |
---|---|
Core Technology | Passive Detection, Broadband Scanning |
Detection Frequency | 300MHz to 6000MHz; 300MHz to 9000MHz (select models) |
Key Detection Frequency Bands | 2.4GHz / 5.8GHz / 800MHz / 900MHz / 1.4GHz / 5.2GHz |
Detection Range | Jdy-900: 1 to 5km; Jdy-900p: 1 to 8km |
Positioning Accuracy | ≤10m (UAV); ≤5m (operator) |
Interference Frequency Bands | 2.4GHz / 5.8GHz / 900MHz / GPS / Beidou / Glonass / Galileo |
Interference Range | 1-3 km (depending on electromagnetic environment) |
Interference Mode | Four-sector directional/omnidirectional strike |
Transmit Power | 360W; 1500W (select models) |
