Product Details
Place of Origin: china
Brand Name: JDY
Model Number: JDY-100
Payment & Shipping Terms
Minimum Order Quantity: 1
Price: $4286
Packaging Details: Flight case
Delivery Time: 30days
Payment Terms: L/C
Supply Ability: 200 per month
|
Fpv Drone:
|
Yes
|
Output Power:
|
≥40dBm
|
Operating Mode:
|
Handheld
|
Supply Voltage:
|
DC: +12V~+28V (battery Optional)
|
Charging Time:
|
About 3 Hours
|
Jamming Frequency:
|
315MHz To 5.8GHz
|
Energy Efficiency:
|
≥50%
|
Power Consumption:
|
≤200W
|
Transmit Power:
|
40dBm Per Channel
|
Display:
|
LED Indicator For Battery And Signal Status
|
Interference Band:
|
900MHz, 1.5Ghz, 2.4Ghz, 5.8Ghz
|
Interference Distance:
|
200-1000M
|
Protection Level:
|
IP55
|
Band:
|
2 Band
|
Detection Band:
|
2.4Ghz, 5.8Ghz
|
|
Fpv Drone:
|
Yes
|
|
Output Power:
|
≥40dBm
|
|
Operating Mode:
|
Handheld
|
|
Supply Voltage:
|
DC: +12V~+28V (battery Optional)
|
|
Charging Time:
|
About 3 Hours
|
|
Jamming Frequency:
|
315MHz To 5.8GHz
|
|
Energy Efficiency:
|
≥50%
|
|
Power Consumption:
|
≤200W
|
|
Transmit Power:
|
40dBm Per Channel
|
|
Display:
|
LED Indicator For Battery And Signal Status
|
|
Interference Band:
|
900MHz, 1.5Ghz, 2.4Ghz, 5.8Ghz
|
|
Interference Distance:
|
200-1000M
|
|
Protection Level:
|
IP55
|
|
Band:
|
2 Band
|
|
Detection Band:
|
2.4Ghz, 5.8Ghz
|
This 2.4G/5.8G Bluetooth handheld drone signal detector features a handheld design, offering exceptional convenience and operability. Its lightweight body makes it easy for users to carry and operate, making it particularly suitable for outdoor detection. Whether in open outdoor environments or confined spaces, it facilitates drone signal detection. The ergonomic design ensures comfortable holding without placing excessive burden on the user, maintaining stability and flexibility for extended periods during use, making it an ideal choice for drone enthusiasts and professionals.
![]()
| Parameters | Specifications |
|---|---|
| Working Mode | Passive detection, does not actively emit electromagnetic signals; |
| Working Frequency Band | 2.4G/5.8G/Bluetooth; |
| Detection Radius | 1-2km (depending on local electromagnetic environment and drone model); |
| Positioning Error | ≤10 meters |
| Detection Quantity | ≥10 drones |
| Flight Duration | ≥8 hours |
| Equipment Weight | Approx. 480 grams (including battery) |
| Screen Size | 5.5-inch IPS HD screen |
| Equipment Dimensions | 214x82x37mm |
This detector is equipped with a 5-inch HD display screen with a resolution of 1920x1080, ensuring that every detail during signal detection is clearly displayed. Users can directly view the detected signal strength, frequency band, and other relevant information on the screen, making operation simple and clear. Whether in daylight or low-light environments, the screen provides a clear display with minimal reflection, facilitating data viewing and making operation more intuitive. The overall display is crisp and clear, providing users with a more accurate signal detection experience.
This signal detector features a built-in high-capacity battery, providing up to 6 hours of continuous use. Users don't need to worry about frequent charging during extended detection periods. The battery charges in approximately 3 hours using fast-charging technology, ensuring efficient operation even during long working hours outdoors. The built-in battery also makes the device more portable, eliminating the need to carry an additional battery pack and reducing burden, providing a more convenient operating experience.
To ensure stable operation in various complex environments, this signal detector features an IPX4 waterproof and dustproof design. Even in rainy or dusty environments, the device continues to operate normally, guaranteeing a long service life. Whether in humid forests or dusty open areas, the device maintains stability and accuracy. This protective design gives the detector strong adaptability to different environments, making it a powerful tool for professionals and drone enthusiasts.
