Product Details
Place of Origin: China
Brand Name: JDY
Model Number: JDY-900P
Payment & Shipping Terms
Minimum Order Quantity: 1
Price: $25714
Packaging Details: flight case
Delivery Time: 30days
Payment Terms: L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability: 200 per month
|
Total Rf Power:
|
≥95W
|
Countermeasure Range:
|
≥1500m
|
Core Working Principle:
|
Electromagnetic Interference Suppression
|
Jamming Response Speed:
|
≤2 Seconds
|
Interference Band:
|
900MHz, 1.5Ghz, 2.4Ghz, 5.8Ghz
|
Jamming Band:
|
2.4G 5.8G 5.2G 433M 900M 1.5GHz
|
Interference Radius:
|
1-2km
|
Operating Temperature:
|
-10°C To 50°C
|
Receiver Tech:
|
LekDro 915MHz Rx ELRS
|
Positioning Accuracy:
|
Using Protocol Analysis For Positioning
|
Response Time:
|
≤2s
|
Max Power Consumption:
|
≤785W
|
Charging Mode:
|
DC25.2V / 3A
|
Device Weight:
|
≤37kg
|
Jamming Modes:
|
5 Bands Selectable
|
|
Total Rf Power:
|
≥95W
|
|
Countermeasure Range:
|
≥1500m
|
|
Core Working Principle:
|
Electromagnetic Interference Suppression
|
|
Jamming Response Speed:
|
≤2 Seconds
|
|
Interference Band:
|
900MHz, 1.5Ghz, 2.4Ghz, 5.8Ghz
|
|
Jamming Band:
|
2.4G 5.8G 5.2G 433M 900M 1.5GHz
|
|
Interference Radius:
|
1-2km
|
|
Operating Temperature:
|
-10°C To 50°C
|
|
Receiver Tech:
|
LekDro 915MHz Rx ELRS
|
|
Positioning Accuracy:
|
Using Protocol Analysis For Positioning
|
|
Response Time:
|
≤2s
|
|
Max Power Consumption:
|
≤785W
|
|
Charging Mode:
|
DC25.2V / 3A
|
|
Device Weight:
|
≤37kg
|
|
Jamming Modes:
|
5 Bands Selectable
|
In modern society, the rapid development of drone technology has brought unprecedented security challenges, especially posing an increasingly serious threat to critical facilities such as government buildings, airports, and military bases. Fixed anti-drone defense equipment has emerged to address this need. It not only effectively counters drone threats but also ensures the safe and stable operation of critical facilities. This defense system provides users with powerful protection capabilities through efficient technical means.
Fixed anti-drone defense equipment is widely used in various critical facilities, especially in high-security locations such as government buildings, airports, military bases, and energy plants. These facilities typically involve national security, public safety, and significant economic interests, making their protection needs particularly urgent. This equipment can monitor drone activity in the airspace in real time and, through identification, tracking, and jamming, effectively intercept drones when they approach, preventing them from entering no-fly zones and ensuring the safety of important facilities.
| Parameter | Description |
|---|---|
| Detection Range | 300MHz-6G |
| Key Detection Frequency Bands | 400M/500M/600M/700M/800M/900M/1.1G/1.2G/1.4G/1.5G/2.4G/3.3G/5.2G/5.8G (customization) |
| Detection Range | 1-8KM |
| Interference Frequency Bands | 900M1.5G2.4G5.2G5.8G |
| Interference Range | > 1-2KM |
| Response Time | ≤3s |
| Product Dimensions | 580*580*320mm |
| Packaging Dimensions | 720*720*455mm |
| Product Weight | 15KG |
| Total Product Weight | 45KG |
This anti-drone defense equipment is equipped with an advanced intelligent alarm system that can issue timely warnings. When a drone enters the designated warning zone, the system automatically identifies and tracks the target, quickly assessing any potential security threat. Upon detecting any anomalies or danger, the alarm system will issue alerts through multiple channels, including visual, auditory, and SMS messages, reminding relevant personnel to take appropriate emergency measures. Furthermore, the system features remote monitoring capabilities, transmitting real-time data to the command center to ensure timely handling of any abnormal situations.
To adapt to different environments and needs, the fixed anti-drone defense equipment supports multi-platform compatibility, seamlessly integrating with various devices and systems. Whether it's traditional monitoring systems, radar systems, or modern intelligent security platforms, effective data exchange and interoperability are achieved. Users can view equipment status, control system operations, and perform remote management through multiple platforms such as PCs and mobile devices. Multi-platform compatibility not only enhances the equipment's flexibility and operability but also provides users with more efficient management tools.
This fixed anti-drone defense equipment is designed for simplicity, with a quick installation process that does not require complex debugging by professional technicians. The equipment is suitable for various scenarios, not only for outdoor installations in critical locations such as airport perimeters, military bases, and energy facilities, but also for flexible indoor deployments in locations such as government buildings and conference centers. Its compact structure and modular design allow for flexible use in different environments while meeting the security requirements of various facilities. Users only need to select the appropriate location and installation method based on their actual needs for rapid deployment.
Through this series of technological innovations, fixed anti-drone defense equipment has become a powerful tool for ensuring the security of critical facilities. It not only plays a significant role in enhancing security capabilities but also makes facility management and operation more intelligent and flexible, becoming an indispensable protective equipment in modern society.
