Home > Products > Anti Drone System > Efficient Anti Drone System 300MHz-6000MHz 500W Manpower Saving

Efficient Anti Drone System 300MHz-6000MHz 500W Manpower Saving

Product Details

Place of Origin: China

Certification: Design Patent Certificate,Computer Software Copyright Registration Certificate,Utility Model Patent Certificate,Testing Report of Lightning Protection Products Testing Center of Shanghai Lightning Protection Center, etc.

Model Number: JDY-2000

Payment & Shipping Terms

Minimum Order Quantity: 1

Price: $ 62820

Packaging Details: Flight Case

Delivery Time: 30 days

Payment Terms: T/T,D/A,L/C,D/P,Western Union,MoneyGram

Supply Ability: 200 per month

Chat Now
Highlight:

Efficient Anti Drone System

,

Efficient drone jammer system

,

500W Anti Drone System

Product Name:
Fixed Uav Detection, Jamming & Deception System
Core Tech:
Passive Detection, 4-Sector Strike, Gnss Deception
Detection Freq:
300MHz~6000MHz; 100MHz~6000MHz (Partial)
Key Detection Bands:
2.4G/5.8g/400MHz/800MHz/900MHz/1.4GHz
Detection Dist:
1~5km; 1~12km (Jdy-2000p)
Jamming Bands:
2.4G/5.2g/5.8g/GPS/Bds/Glonass/Galileo
Jamming Dist:
1~3km; 1~5km (Jdy-2000p)
Deception Signals:
GPS/Bds/Glonass/Galileo
Deception Dist:
500~1000m
Transmission Power:
500W; ≤2000W (Jdy-2000p Total)
Power Supply:
AC220V→DC24V; DC27V (Partial)
Weight:
≤15kg; ≤50kg (Jdy-2000p)
Operating Temp:
-35ºC~50ºC (Built-in Radiator)
Protection Level:
IP66
Positioning Accuracy:
≤10m (Uav); ≤5m (Operator)
Product Name:
Fixed Uav Detection, Jamming & Deception System
Core Tech:
Passive Detection, 4-Sector Strike, Gnss Deception
Detection Freq:
300MHz~6000MHz; 100MHz~6000MHz (Partial)
Key Detection Bands:
2.4G/5.8g/400MHz/800MHz/900MHz/1.4GHz
Detection Dist:
1~5km; 1~12km (Jdy-2000p)
Jamming Bands:
2.4G/5.2g/5.8g/GPS/Bds/Glonass/Galileo
Jamming Dist:
1~3km; 1~5km (Jdy-2000p)
Deception Signals:
GPS/Bds/Glonass/Galileo
Deception Dist:
500~1000m
Transmission Power:
500W; ≤2000W (Jdy-2000p Total)
Power Supply:
AC220V→DC24V; DC27V (Partial)
Weight:
≤15kg; ≤50kg (Jdy-2000p)
Operating Temp:
-35ºC~50ºC (Built-in Radiator)
Protection Level:
IP66
Positioning Accuracy:
≤10m (Uav); ≤5m (Operator)
Efficient Anti Drone System 300MHz-6000MHz 500W Manpower Saving

When illegal drones frequently appear in sensitive areas, traditional security measures often struggle to cope. The Fixed Detection, Interference, and Deception Drone Defense System (FDID) is a comprehensive solution designed to address this pain point.

Solution Framework
  • Detection: The system automatically monitors the low-altitude spectrum to identify the source of drone signals.
  • Identification: Intelligent algorithms analyze the model, frequency band, and flight trajectory.
  • Intervention: Precisely jams illegal targets, shutting down remote control and image transmission.
  • Deception: Uses fake navigation signals to guide drones to a safe area for forced landing.
  • Management: Centralized back-end monitoring generates airspace safety reports for easy traceability.
System Value
  • Full-Process Coverage: From detection to action, a closed-loop system is created.
  • Risk Reduction: Effectively prevents potential threats such as surreptitious filming, jamming, and drone delivery.
  • Compliance and Security: Does not impact normal communications or legal flights.
  • Manpower Savings: Automated operations reduce the pressure on security personnel.
Customer Benefits
  • Airport Operators: Ensures normal flight takeoffs and landings.
  • Energy companies: Protect power grids and oil and gas facilities.
  • Large-scale event organizers: Create a safe atmosphere for spectators and participants.
  • Government agencies: Improve public safety management.

With this system, users can establish a "visible, manageable, and controllable" low-altitude defense system, achieving true airspace security.

Product Name Fixed UAV Detection, Jamming & Deception System
Core Technology Passive Detection, Four-Sector Strike, GNSS Spoofing
Detection Frequency 300MHz-6000MHz; 100MHz-6000MHz (select models)
Key Detection Frequency Bands 2.4GHz / 5.8GHz / 400MHz / 800MHz / 900MHz / 1.4GHz
Detection Range 1-5km; 1-12km (JDY-2000p)
Jamming Frequency Bands 2.4GHz / 5.2GHz / 5.8GHz / GPS / Beidou / Glonass / Galileo
Jamming Range 1-3km; 1-5km (JDY-2000p)
Spoofing Signals GPS / Beidou / Glonass / Galileo
Spoofing Range 500-1000m
Transmit Power 500W; ≤2000W (JDY-2000p total power)
Power Supply AC220V → DC24V; DC27V (select models)
Weight ≤15kg; ≤50kg (JDY-2000p)
Operating Temperature -35°C to +50°C (built-in heat sink)
Protection Rating IP66
Positioning Accuracy ≤10m (UAV); ≤5m (operator)
