Product Details
Place of Origin: China
Brand Name: jindowin
Certification: Design Patent Certificate,Computer Software Copyright Registration Certificate,Utility Model Patent Certificate,Testing Report of Lightning Protection Products Testing Center of Shanghai Lightning Protection Center, etc
Model Number: JDY-400
Payment & Shipping Terms
Minimum Order Quantity: 1
Price: $5000
Packaging Details: Flight Case
Delivery Time: 30 days
Payment Terms: D/A,D/P,L/C,T/T,Western Union,MoneyGram
Supply Ability: 5000 per month
|
Channel 1 - 6:
|
400MHz ~ 1200MHz
|
Channel 6 - Output Power:
|
47dBm (50W)
|
Supply Voltage:
|
DC +12V~+28V (supports Battery Power, Battery Optional)
|
Max Power Consumption:
|
≤600W
|
Energy Efficiency:
|
≥50%
|
Device Dimension:
|
45cm × 37cm × 22cm
|
Device Weight:
|
≤14kg
|
Power Interface:
|
Aviation Socket WS20-2
|
RF Interface:
|
N-J Type, Impedance 50Ω
|
Antenna Type:
|
Omnidirectional FRP Spring Antenna
|
Antenna Power Capacity:
|
100W
|
Antenna Gain:
|
3±1dBi
|
Standard Accessories:
|
Wired Power Box (1PCS), Strong Magnetic Screws (6PCS), Adapters (6PCS)
|
Applicable Scenarios:
|
Security For Small-to-Medium-Sized Events, Airspace Control In Scenic Areas, Protection For Corporate Factories, Protection For Outdoor Exhibitions, Security For Cultural Heritage Protection Areas
|
|
Channel 1 - 6:
|
400MHz ~ 1200MHz
|
|
Channel 6 - Output Power:
|
47dBm (50W)
|
|
Supply Voltage:
|
DC +12V~+28V (supports Battery Power, Battery Optional)
|
|
Max Power Consumption:
|
≤600W
|
|
Energy Efficiency:
|
≥50%
|
|
Device Dimension:
|
45cm × 37cm × 22cm
|
|
Device Weight:
|
≤14kg
|
|
Power Interface:
|
Aviation Socket WS20-2
|
|
RF Interface:
|
N-J Type, Impedance 50Ω
|
|
Antenna Type:
|
Omnidirectional FRP Spring Antenna
|
|
Antenna Power Capacity:
|
100W
|
|
Antenna Gain:
|
3±1dBi
|
|
Standard Accessories:
|
Wired Power Box (1PCS), Strong Magnetic Screws (6PCS), Adapters (6PCS)
|
|
Applicable Scenarios:
|
Security For Small-to-Medium-Sized Events, Airspace Control In Scenic Areas, Protection For Corporate Factories, Protection For Outdoor Exhibitions, Security For Cultural Heritage Protection Areas
|
Professional Hand-Pushed Drone Detection and Countermeasure Equipment
Strong anti-vibration design ensures stability in complex environments
This professional hand-pushed drone detection and countermeasure equipment employs an advanced anti-vibration design, ensuring stable operation in various complex environments. Whether on uneven ground or in environments with frequent vibrations, the equipment maintains high performance and stable operation. Its high-strength structural materials and optimized internal component layout effectively prevent external impacts on equipment functionality, ensuring long-term stable operation in harsh environments. This design allows for wide application in various industries, including security, military, and large-scale event monitoring.
![]()
Product Parameter Table
Parameter Description
| Parameter | Description |
|---|---|
| Detection Range | 1-3 km |
| Countermeasures | Directional interference, signal shielding |
| Operating Temperature | -20°C to +60°C |
| Seismic Resistance | Level 3 |
| Communication | Wireless communication (Wi-Fi, 4G, 5G) |
| Battery Life | 8 hours |
| Equipment Weight | 20 kg |
| Thermal Imaging Resolution | 640x480 |
| Automation Upgrade Function | Supports remote automation upgrades |
| Shell Material | High-strength aluminum alloy |
Built-in Wireless Communication Module, Supporting Data Synchronization
This device is equipped with a built-in wireless communication module, supporting Wi-Fi, 4G, and 5G networks, enabling real-time data synchronization between the device and the command center. This function allows operators to view the device's status in real-time at a remote monitoring center and react promptly based on feedback data. Furthermore, the device supports multi-platform data transmission and control, ensuring that various devices can work collaboratively in multi-point deployment scenarios, providing comprehensive protection.
Powerful Thermal Imaging Technology, Adaptable to Low Visibility Conditions
This device is equipped with advanced thermal imaging technology, enabling accurate identification of target drones under low visibility conditions. Whether in complex environments such as nighttime, fog, or smog, thermal imaging technology leverages its unique advantages to capture the thermal radiation signals of targets, ensuring accurate target tracking and countermeasures even in extremely low visibility conditions. This gives the equipment a significant advantage when performing nighttime patrols or emergency missions.
The system supports automated upgrades, ensuring long-term technological leadership.
To ensure the equipment remains at the forefront of technology, the system supports remote automated upgrades. Users do not need to manually update; the system automatically updates to the latest software version, ensuring continuous optimization of the equipment's functionality and performance. Furthermore, the system has intelligent learning capabilities, automatically adjusting parameters based on usage and environmental changes to ensure optimal reaction speed and interference effectiveness. This feature allows the equipment to maintain a long-term technological lead, avoiding decreased efficiency due to technological obsolescence.
