Product Details
Place of Origin: China
Certification: Design Patent Certificate,Computer Software Copyright Registration Certificate,Utility Model Patent Certificate,Testing Report of Lightning Protection Products Testing Center of Shanghai Lightning Protection Center, etc.
Model Number: JDY-600B
Payment & Shipping Terms
Minimum Order Quantity: 1
Price: $40200
Packaging Details: Flight Case
Delivery Time: 30 days
Payment Terms: T/T,L/C,D/P,D/A,Western Union,MoneyGram
Supply Ability: 200 per month
Product Name:
|
Jdy-600b Wrist Uav Countermeasure Equipment
|
Core Tech:
|
Electromagnetic Suppression, Navigation Deception
|
Detection Freq:
|
300MHz~6000MHz
|
Key Detection Bands:
|
2.4G/5.8g/800MHz/900MHz/1.4G/1.6g/5.2GHz
|
Detection Dist:
|
1~3km (Depends On Electromagnetic Environment)
|
Jamming Bands:
|
902-928MHz/2.4-2.4835GHz/5.15-5.25GHz/5.8GHz
|
Jamming Dist:
|
≥1.5km; 1~2km (Partial Versions)
|
Deception Signals:
|
GPS/Bds/Glonass/Galileo
|
Deception Dist:
|
≥1km (with Directional Antenna)
|
Power Supply:
|
AC220V→DC24V, 29.4V Lithium Battery
|
Weight:
|
≤11kg (Backpack Part); ≤15kg (Total)
|
Operating Temp:
|
-20ºC~50ºC; -35ºC~75ºC(Partia)
|
Protection Level:
|
Ipx1 (Customizable); IP66 (Partial)
|
Control Mode:
|
Wristwatch Terminal (Touch, Vibration Alert)
|
Alarm Mode:
|
Audible/Visual (Adjustable)
|
Product Name:
|
Jdy-600b Wrist Uav Countermeasure Equipment
|
Core Tech:
|
Electromagnetic Suppression, Navigation Deception
|
Detection Freq:
|
300MHz~6000MHz
|
Key Detection Bands:
|
2.4G/5.8g/800MHz/900MHz/1.4G/1.6g/5.2GHz
|
Detection Dist:
|
1~3km (Depends On Electromagnetic Environment)
|
Jamming Bands:
|
902-928MHz/2.4-2.4835GHz/5.15-5.25GHz/5.8GHz
|
Jamming Dist:
|
≥1.5km; 1~2km (Partial Versions)
|
Deception Signals:
|
GPS/Bds/Glonass/Galileo
|
Deception Dist:
|
≥1km (with Directional Antenna)
|
Power Supply:
|
AC220V→DC24V, 29.4V Lithium Battery
|
Weight:
|
≤11kg (Backpack Part); ≤15kg (Total)
|
Operating Temp:
|
-20ºC~50ºC; -35ºC~75ºC(Partia)
|
Protection Level:
|
Ipx1 (Customizable); IP66 (Partial)
|
Control Mode:
|
Wristwatch Terminal (Touch, Vibration Alert)
|
Alarm Mode:
|
Audible/Visual (Adjustable)
|
The JDY-600B wrist-worn drone detection and deception device is an advanced counter-drone device that integrates detection, strike, deception, and networking capabilities. It utilizes high-precision passive detection technology to quickly identify and accurately locate intruding drones. It not only effectively disrupts a drone's image transmission and navigation signals, forcing it to return or make an emergency landing, but also features a deception function, causing drones to become "lost" after entering a controlled area, preventing them from following their intended flight path and thus ensuring airspace safety.
Full-band detection and countermeasures: Supporting frequency bands from 300MHz to 6000MHz, it can detect and effectively counter over 98% of consumer drones on the market.
Deception Capability: It can simulate satellite navigation signal interference, preventing drones from following their designated flight path, with a maximum deception range of up to 1.5 kilometers.
High-efficiency jamming: With a maximum jamming range of 1.5 kilometers, it supports common frequency bands such as 2.4GHz and 5.8GHz, accurately disrupting remote control, image transmission, and navigation signals.
Portability and Flexibility: Weighing less than 11kg, the device features a backpack design and wrist-worn controls, freeing your hands and making it suitable for a variety of patrol missions.
Versatile Usage: It can be controlled via a watch or connected to a computer as a fixed device, adapting to different operational needs.
The JDY-600B provides all-weather, all-around countermeasures and protection, offering a flexible and efficient drone defense solution for various security scenarios.
Detection frequency | 300MHz~6000MHz |
---|---|
Detection false alarm rate | ≤1 time/12 hours |
Detection distance | 1-3000m (subject to local electromagnetic environment) |
Decoy effective distance | ≥ 1000m |
Detection frequency bands | 2.4G/5.8G/800MHz/900MHz/1.4GHz |
Decoy effective orientation | Horizontal beam ≥30°, pitch beam >20° |
Countermeasure distance | ≥ 1500m (subject to local electromagnetic environment) |
Jamming device power | ≥ 10w |
Decoy signals | GPS/BDS/GLONASS/Galileo |
Alarm mode | Sound and light alarm (adjustable) |
Functions | No-fly zone enforcement, repulsion |
The Backpack Drone Jammer features a backpack-mounted design for portability and flexibility, making it ideal for long-distance patrols, mobile security, and emergency response.
The portable backpack design eliminates the need for additional transportation and allows users to maintain continuous protection while on the move, making it particularly suitable for long-duration missions and large-scale patrols.
